Eddy current probes



ECP type Sizes of working surface, mm Operating frequency,dimensions, кHz Overall dimensions mm Detected flaws
1 SS1.5M05DA0 Ø5 500- 2000 Ø 13 x 35 Surface defects in different conductive materials (e.g. aluminum alloys, ferromagnetic and austenitic steels.)
2 SS650K06DA0 Ø 6 500- 1500 Ø 13 x 35
3 SS400K07DA0 Ø 7 300-600 Ø 13 x 35
4 SS300K08DA0 Ø 8 200- 400 Ø 13 x 35
5 SS340K09DA0* Ø 9 250- 400 Ø 13 x 35 Surface and subsurface cracks, pores, corrosive defects in aluminum alloys, ferromagnetic and austenitic steels and etc.
6 SS170K13DA0* Ø 13 100- 250 Ø 13 x 35
7 SS50K15DA0 Ø 15 50- 150 Ø 15 x 50
8 SS10K33DA0 Ø 33 1- 100 Ø 33 x 50
9 SU450K3А6х8A0 Ø 6 x 8 900x1700 Ø 12,5 x 130 Surface cracks in rectangular grooves of products made of ferromagnetic and austenitic steels and etc.
10 SU450K05DA0 Ø 5 400-600 Ø 12,5 x 70 Surface cracks in aluminum alloys, ferromagnetic and austenitic steels and etc.
11 SU450K5А05DA0 Ø 5 400-600 Ø 12.5 x135
12 SU1.8М3.5DS01 Ø 3,5 1000-1900 Ø 9,6 x 55 Surface cracks in aluminum alloys, titanium alloys and etc.
13 SU1.8М3А3.5DS01 Ø 3,5 400-600 Ø 9.6 x160
14 SU450K05DA4 Ø 5 750-1100 Ø 15 x170 Surface cracks, pores, corrosive damages in aluminum alloys, ferromagnetic and austenitic steels and etc.
15 SU300K08DA0 Ø 8 100-450 Ø 35 x150
16 SU350K6x0.5DA1 6 x 0,5 350-600 Ø 12 x 61 Testing for the presence of surface cracks in a metric thread with a step of 2 mm made on products of ferromagnetic material. Used with the SKV-MR-01 scanner.
17 SU350K6x0.5DA2 6 x 0,5 350-600 Ø 12 x 61 Testing for the presence of cracks in a metric thread with a step of 4 mm made on products of ferromagnetic material. Used with the SKV-MR-02 scanner.
18 SU350K6x0.5DA3 6 x 0,5 350-600 Ø 12 x 61 Testing for the presence of surface cracks in metric thread with a step of 6, 35 mm made of ferromagnetic material. Used with the SKV-MR-03 scanner.
19 SU350K6x0.5DA4 6 x 0,5 350-600 Ø 12 x 61 Testing for the presence of surface cracks in a metric thread with a step of 1,5 mm made on products made of ferromagnetic material. Used with the SK-MR-04
20 SU350K6x0.5DA5 6 x 0,5 350-600 Ø 12 x 61 Testing for the presence of surface cracks in a metric thread with a step of 5,08 mm made on products of ferromagnetic material. Used with the SKV-MR-05 scanner.
21 RO1.7M5A9DFD0 Ø 9 1500-2500 Ø 9 x 55 Detection of surface defects in parts holes made of aluminum alloys, ferromagnetic and austenitic steels.
22 SU30К16DD0 Ø 16 30-200 Ø 50 x 55 Special-purpose probe for detection of surface cracks in fencing epees, made of austenitic steels.

* - probes in protective case with the wearproof protector.

New types of probes can be developed according to the Customer`s requirement specifications.
